DESCRIPTION
1. Low voltage supply
The voltage used to drive the thermal printer head is equal to the logic voltage, or is driven by a 5 V single power line, the range of operating voltage is 4.2V-8.5V, so four to six NI-Cd batteries or Ni-MH batteries can also be used. Two li-ion batteries can be used.
2. Compact and lightweight design
The mechanism is compact and light, dimensions: 91.7mm (width) * 32.7mm (depth) * 15.5mm (height)
3. Printing with high resolution
A high-density printer head of 8 dots/mm makes the printing clear and precise
4. High speed printing
According to driving power and sensitivity of thermal paper, set different printing speed required. Printing speed is 80 mm/ s(max.)
5. Easy paper loading
Detachable rubber roller structure makess the paper loading easier
6. Low noise
Thermal line dot printing is used to guarantee low noise printing.

SPECIFICATION
Print Method: Direct line thermal
Resolution: 8 dots/mm
Max. Printing Width: 72mm
Number of Dots: 576
Paper Width: 79.5±0.5mm
Max. Printing Speed: 80mm/s

POWER SUPPLY
TPH Logic Voltage: 2.7V-5.5V
Drive Voltage: 4.2V - 8.5V

Dimensions(W*D*H): 91.7*32.7*15.5mm
Mass: 52g

Application
Measuring devices, Medical equipment, Weighing scales
